LQ105
Features
- For Load and Inflation Pressure on agricultural tractors, please consult the technical department.
- For tractor steer wheels, load is 80% of free rolling load.
- For 12.5/80-18, the load capacity and inflation pressure is for free rolling application.
Suitable Conditions
bias otr tyre
Share To:
Suitable
Size And Specs
| Tyre Size | PR | Tread Pattern | Tread Depth (mm) | Rim Size | Tube Type | Inflated Dimensions (mm) | Speed Symbal | Inflation Pressure (kPa) | Maximum Load Versus Speed(KG) | |||||||
| Type | TRA Code | |||||||||||||||
| Outer Diameter | Section Width | 0km/h | 15km/h | 25km/h | 30km/h | 40km/h | 50km/h | |||||||||
| 12.5/80-18 (IMP) | 12 | LQ105 | R4 | 28 | W9*18 (11*18) | TBLS | 1014 | 322 | A6 | 370 | 4375 | 3205 | 2835 | 2650 | 2385 | - |
| 16.9-24 (IND) | 8 | LQ105 | R4 | 26 | W15L*24 (W14L*24) | TBLS | 1351 | 464 | A8 | 190 | 6095 | 3550 | 2940 | 2835 | 2650 | 2410 |
| 10 | LQ105 | R4 | 26 | TBLS | 1351 | 464 | A8 | 220 | 6900 | 4040 | 3330 | 3210 | 3000 | 2730 | ||
| 12 | LQ105 | R4 | 26 | TBLS | 1351 | 464 | A8 | 260 | 7475 | 4355 | 3610 | 3480 | 3250 | 2960 | ||
| 17.5L-24 (IND) | 6 | LQ105 | R4 | 29 | W15L*24 (W14L*24) | TBLS | 1278 | 480 | A8 | 140 | 4600 | 2680 | 2220 | 2140 | 2000 | 1820 |
| 8 | LQ105 | R4 | 29 | TBLS | 1278 | 480 | A8 | 170 | 5590 | 3255 | 2695 | 2600 | 2430 | 2210 | ||
| 10 | LQ105 | R4 | 29 | TBLS | 1278 | 480 | A8 | 220 | 6440 | 3750 | 3110 | 2995 | 2800 | 2550 | ||
| 12 | LQ105 | R4 | 29 | TBLS | 1278 | 480 | A8 | 260 | 7475 | 4355 | 3610 | 3480 | 3250 | 2690 | ||
| 19.5L-24 (IND) | 8 | LQ105 | R4 | 27 | W16L*24 (DA16A,W15L*24) | TBLS | 1356 | 535 | A8 | 170 | 6270 | 3650 | 3025 | 2915 | 2725 | 2480 |
| 10 | LQ105 | R4 | 27 | TBLS | 1356 | 535 | A8 | 190 | 7075 | 4120 | 3415 | 3290 | 3075 | 2800 | ||
| 12 | LQ105 | R4 | 27 | TBLS | 1356 | 535 | A8 | 230 | 7935 | 4625 | 3830 | 3690 | 3450 | 3140 | ||
| 14 | LQ105 | R4 | 27 | TBLS | 1356 | 535 | A8 | 260 | 8915 | 5195 | 4300 | 4145 | 3875 | 3525 | ||
| 21L-24 (IND) | 10 | LQ105 | R4 | 37 | W18L*24 (W18*24,DW18A*24) | TBLS | 1424 | 576 | A8 | 180 | 7705 | 4490 | 3720 | 3585 | 3350 | 3050 |
| 12 | LQ105 | R4 | 37 | TBLS | 1424 | 576 | A8 | 220 | 8915 | 5195 | 4300 | 4145 | 3875 | 3525 | ||
| 16 | LQ105 | R4 | 37 | TBLS | 1424 | 576 | A8 | 280 | 10350 | 6030 | 4995 | 4815 | 4500 | 4095 | ||
| 18.4-26 (IND) | 12 | LQ105 | R4 | 27 | W16L*26 (DW16A,W15L*26) | TBLS | 1523 | 505 | A8 | 250 | 9200 | 5360 | 4440 | 4280 | 4000 | 3640 |
| 16.9-28 (IND) | 12 | LQ105 | R4 | 32 | W15L*28 (W14L*28) | TBLS | 1452 | 464 | A8 | 260 | 8165 | 4755 | 3940 | 3800 | 3550 | 3230 |
| Size | PR | PTTERN | S.R. | S.W. | O.D. | Tube type | Loading (kg) | Pressure (kpa) | |
| TYPE | TRA CODE | （mm) | (mm) | ||||||
| 16.9-24 | 8 | MX105 | R-4 | W15L | 430 | 1309 | TL | 2650 | 190 |
| 10 | H658 | 2900 | 220 | ||||||
| 16.9-28 | 10 | MX105 | R-4 | W15L | 430 | 1410 | TL | 2380 | 200 |
| 12 | 2730 | 240 | |||||||
| 17.5L-24 | 10 | MX105 | R-4 | W15L | 445 | 1241 | TL | 2800 | 220 |
| 12 | 3075 | 260 | |||||||
| 19.5L-24 | 10 | MX105 | R-4 | DW16A | 495 | 1314 | TL | 3000 | 190 |
| 12 | 3450 | 230 | |||||||
| 21L-24 | 10 | MX105 | R-4 | DW18A | 533 | 1378 | TL | 3350 | 180 |
| 12 | 3875 | 220 | |||||||
| 18.4-26 | 10 | MX105 | R-4 | W16L | 467 | 1438 | TL | 2645 | 180 |
| 12 | 2985 | 230 | |||||||
| 18.4-28 | 10 | MX105 | R-4 | W16L | 467 | 1488 | TL | 2715 | 180 |
| 12 | 3135 | 220 | |||||||
| Size | PR | S.R. | S.W. | O.D. | Loading (kg) | Pressure (kpa) | |||
| （mm) | (mm) | ||||||||
| 10.5/80-18 | 10 | MX105 | R-4/ I-3 | W9 | 274 | 907 | TL | 1360 | 370 |
| 12 | HK659 | 1550 | 420 | ||||||
| 12.5/80-18 | 12 | MX105 | R-4/ I-3 | W9 | 308 | 987 | TL | 1850 | 370 |
| 14 | 2120 | 430 | |||||||
